Mitsubishi's NF63-CV 20A is a three-pole Molded Case Circuit Breaker (MCCB) with a rated current of 20 A, designed for the protection of electrical circuits from overloads and short circuits. Technical Specifications
Product Type: No Fuse Breaker (NFB) / Molded Case Circuit Breaker (MCCB)
Series: NF-C Series (economy class)
Number of Poles: 3 Poles (3P)
Rated Current (A): 20 A
Current Frame: (AF) 50 AF
Breaking Capacity: (Icu) 2.5 kA at 380/415 VAC
Insulation Voltage (Ui): 600 V
Operational Voltage: 400 VAC (breaking capacity 5 kA)
Mounting Method: Fixed Type, Fastened with Screws
Connection Method: Front Connection, Embedded Type
Standards Comply with IEC60947-2, PSE / CE / CCC
Dimensions (H x W x D): 130 x 75 x 90 mm
